Cu / PVC control cables copper wire braiding screened flxible cable for construction

Product name: Cu /PVC control cable copper wire braiding screened flxible cable for construction

Product description :The product is applicable for AC50 Hz transmission and distribution lines with rated voltage 450/750KV.

The mechanical properties and electrical performance of cables meet the requirements of national standard GB/T9330.2-2008.

Laid indoors, and in tunnels, pipelines(include cable duct), and can not bear external mechanical forces.

Constructions

Conductor: class 5 copper conductor

insulation: PVC insulation

Screen: tinned copper wire screen

Outer sheath: PVC sheath

Note: Insulation color as per standards or at request

Applications

Fixed laying indoors with capability of moving an screening

Standards

International: IEC 60502-2, IEC 60228

China: GB/T 12706.2-2008

Other standards such as BS,DIN and ICEA upon request

Technical data

Rated voltage:450V/750V

Maximum Conductor Temperature: under normal (90°C), emergency (110°C) or short circuit no more than 5 s (250°C) conditions.

Min. Ambient Temp. 0°C, after installation and only when cable is in a fixed position

Min. Bending Radius: 20 x cable O.D for single-core non-armoured cables

Certificates

CE, RoHS, CCC, KEMA and more others at request
